Item name: China UV plate wholesale 0.27mm gauge 200LPI up to 100000 impressions spectral sensitivity 405nm

FUCAI CTP Plate(Thermal VS UV PS Plate)
Technical specification
Products Type	(FP-100) Positive Thermal Plates	(FP-200) UV Plates
Durable Rate	50,000~100,000 impressions unbaked; >=100,000 impression baked;	>=100,000 impressions
Thickness	0.27mm, 0.15mm	0.27mm, 0.15mm
Sensitive wavelength	830nm	405nm
Laser energy required	110~150mj/cm	50~70mj/cm
Resolution	1%~99%@200lpi	1%~99%@200lpi
Baking condition	230˚C-250˚C, 5~8 minutes (by using professional plate baking glue)	230˚C-250˚C, 5~8 minutes (by using professional plate baking glue)
Safe lighting	2 hours under fluorescent lamp, 12 hours under yellow safelight	2 hours under fluorescent lamp, 12 hours under yellow safelight
Storage condition	Store in dry and cool place, store in 5˚C~30˚C, Humility <55%	Store in dry and cool place, store in 5˚C~30˚C, Humility <55%
Shelf life	12 months	12 months
Developing time	20sec~30sec	20sec~30sec
Productivity	1800m2~2500m2	1800m2~2500m2

Item Name	PS Plate
Plate type	Positive
Substrate	Electro-chemically grained and anodized lithographic aluminum.
Gauge	0.15/0.27/0.30mm
Maximum width	1320mm
Spectral sensitivity	350-420nm
Safelights	UV filtered or Yellow
Sensitivity	130-150mj/cm²
Color change	Blue-Green to Green after exposed
Dot reproduction	1~99% @200LPI
Packing	0.15mm 100pcs/box, 0.27/0.30mm 50pcs/box
Shelf life	12 months
Run length	up to 100,000 impressions

HIGH-QUALITY PRINTING

LONG PROCESSING CYCLES

ENVIRONMENT PROTECTION

Shenzhen Yintech Co., Ltd. is a national high-tech enterprise integrating independent R&D, manufacturing and marketing. It has a deep technical accumulation in laser modulation technology, image control technology and platform motion control technology. The company has developed CTCP, CTP, CTS, LDI and photolithography equipment with independent intellectual property rights and reached the international advanced level by using more than ten years of technology accumulation and professional R&D team. It has sold thousands of sets at home and abroad. After more than ten years of precipitation, the company's export business has covered more than 100 countries and regions. In the future, the company will strive to become a leading enterprise in the fields of lithography, new generation of high-end new printing, PCB equipment and semiconductor manufacturing.

Our company has strong strength and established a new company Hunan Yintech Co., Ltd with the government, which covers an area of 30 acres with a total investment of 600 million RMB. It is mainly used to invest in the production of lithography machines, printed circuit boards, laser direct imaging equipment, printing plate-making equipment and related accessories, as well as laser plate-making equipment assembly and production.
